Mobil ATF SHC™
Product Description
Mobil ATF SHC™ is a superior performance synthetic automatic transmission fluid designed to meet the demanding requirements of automatic transmissions operating in the severe, high-temperature, and heavy load applications. The inherently high viscosity index and stability of Mobil ATF SHC protects against thermal breakdown at high operating temperatures enabling outstanding low temperature performance at ambient temperatures below "40ºC.
Features and Benefits
Mobil ATF SHC combines high performance synthesised hydrocarbon base oils with a balanced additive system to provide a significantly higher level of performance versus conventional fluids. This automatic transmission fluid ensures long fluid life, improved transmission cleanliness, excellent shift performance and extended transmission life under all operating conditions and performance levels. Key features and benefits include:
| Features | Advantages and Potential Benefits |
| Enhanced, long-term frictional properties | Improves and extends transmission efficiency, smooth shifting performance and potentially fuel savings |
| Outstanding thermal and oxidation stability | Keeps transmissions clean to extend life and performance even under severe operating conditions |
| Outstanding film-strength and anti-wear properties | Significant wear reduction and longer transmission life |
| Excellent low-temperature fluidity | Provides prompt and reliable lubrication at ambient temperatures below "40º C |
| Exceptional shear stability | Viscosity retention even under the severest heavy duty, high temperature operating conditions |
| Compatible with mineral ATF fluids and all common seal materials | Reduced concern in top-off emergencies and excellent leakage control |
Applications
Mobil ATF SHC is recommended by ExxonMobil for use in modern high performance transmissions operating in the severe, high-temperature, heavy load or cold climate applications. It is ideal for manual transmissions designed to operate with ATF fluids, where it will provide excellent gear shifting and protection under severe operating conditions.
Specifications and Approvals
| Mobil ATF SHC has the following builder approvals: | |
| ZF TE-ML 14B | X |
| ZF TE-ML 16L | X |
| ZF TE-ML 09X | X |
| MB-Approval 236.8 | X |
| MAN 339 TYPE Z2 | X |
| MAN 339 TYPE V2 | X |
| According to ExxonMobil, Mobil ATF SHC is of the following quality level: | |
| GM DEXRON IIE | X |
| ALLISON C-4 | X |
| CAT TO-2 | X |
| RENK DOROMAT | X |
Typical Properties
| Mobil ATF SHC | |
| Viscosity, ASTM D 445 | |
| cSt @ 40°C | 33 |
| cSt @ 100°C | 7.4 |
| Brookfield Viscosity, ASTM D 5293 | |
| -cP @ -40°C | 7000 |
| Viscosity Index, ASTM D 2270 | 200 |
| Pour Point, °C, ASTM D 97 | -51 |
| Flash Point, °C, ASTM D 92 | 210 |
| Density @15°C, kg/l, ASTM D 4052 | 0.839 |
| Colour | Red |
